HG57500C GOTTIUG 频率发生器

产品型号:HG57500C
联系人:何姗姗
手机:18059884797(微信同号)
QQ:3095989363
地址:福建省漳州开发区南滨大道429号招商局芯云谷3号楼217-01
联系电话:18059884797

详细介绍


产品描述
HG57500C GOTTIUG频率发生器产生具有精 确频率和振幅的信号。

特征
双环频率发生器
与引导天线一起使用
2个发生器通道,每个通道有16个可选频率
支持堆叠
欧洲卡格式,适用于19″机架
生成I=30至200 mA的交流电流(取决于型号,请参阅数据表上的表格)

功能说明
HG57500C GOTTIUG频率发生器在导电环路中产生交流电流,用于自动导引车(AGV)的轨道引导。该板配有两个独立的发电机,带有功率放大器和一个用于直流去耦的变压器。频率存储在EPROM中,并且可以使用16位十六进制开关或4个数字输入进行选择。

两台发电机通过不同的变压器进行伏特转换,因此可以单独调节并设置为提供恒定的输出水平。短路和断路可通过前面板上的LED进行检测和指示。

每个发生器提供2组独立的连接器,用于连接短环路或长环路。短环路和对数环路之间的大负载阻抗和电流之差约为1:2。微调电位器“Strom 1”、“Strom 2”同时影响两个输出。

对于高于100欧姆的负载阻抗,感性电抗分量可以通过必须组装在电路板上的电容器来平衡(使用输出“闭环长补偿”)。必须针对每个应用确定容量。

此外,频率发生器支持堆叠。这意味着板上的两个发电机可以串联。因此,可以为环路提供两倍的阻抗。

HG57500C GOTTIUG频率发生器是一款高性能仪器,专为产生特定频率的电信号而设计。它提供了从1µHz到50MHz的宽频率范围以及高精度和稳定性。它有多个输出接口,包括正弦波、方波和TTL输出。该仪器操作简单,界面友好。

应用领域
HG57500C GOTTIUG频率发生器广泛用于电子器件的测试和校准,以及电子电路的研发。适用于科研、教育、生产等领域。
HG57500C   GOTTIUG   频率发生器
Product description
The HG57500C GOTTIUG frequency generator produces a signal with precise frequency and amplitude.

trait
Double ring frequency generator
Use with a pilot antenna
2 generator channels, each with 16 selectable frequencies
Stack support
European card format for 19 "racks
Generate I=30 to 200 mA AC current (depending on model, see table on data sheet)

Function description
The HG57500C GOTTIUG frequency generator generates alternating current in a conductive loop for track guidance of an automated guided vehicle (AGV). The board is equipped with two independent generators with power amplifiers and a transformer for DC decoupling. The frequency is stored in the EPROM and can be selected using a 16-bit hexadecimal switch or a 4-digit input.

The two generators convert voltages through different transformers, so they can be individually adjusted and set to provide a constant output level. Short circuits and breaks can be detected and indicated by leds on the front panel.

Each generator provides 2 separate sets of connectors for connecting short or long loops. The difference between the maximum load impedance and current between the short loop and the logarithmic loop is about 1:2. Fine-tuning potentiometers "Strom 1" and "Strom 2" affect both outputs at the same time.

For load impedance higher than 100 ohms, the inductive reactance component can be balanced by capacitors that must be assembled on the board (using output "closed-loop length compensation"). Capacity must be determined for each application.

In addition, the frequency generator supports stacking. This means that the two generators on the board can be connected in series. Thus, twice the impedance can be provided to the loop.

The HG57500C GOTTIUG frequency generator is a high performance instrument designed to generate electrical signals of a specific frequency. It provides a wide frequency range from 1µHz to 50MHz as well as high accuracy and stability. It has multiple output interfaces, including sine wave, square wave, and TTL outputs. The instrument has simple operation and friendly interface.

Application field
The HG57500C GOTTIUG frequency generator is widely used in the testing and calibration of electronic devices, as well as the development of electronic circuits. Applicable to scientific research, education, production and other fields.
